Summary of XC series PLC
• XC series PLC can be used independently or used along with
the expansions. The following is the chart of a basic unit with
seven expansions.
• Digital Input/Output quantity is Octal
• Analogue Input/Output quantity is Decimal
• PLC main units can connect with 7 expansions and a BD
module. The input/output type is not limited, both switch and
analog quantity are available.
1-3. Expansion’s constitution and ID assignment
Expansion
Constitution
Rules
10
