Thinget XC3-48R-E User Manual

Summary of XC series PLC
XC3 series models:
Model
AC Power DC Power
Relay Output Transistor
Output
Mix output
(R&T)
Relay Output Transistor
Output
Mix output
(R&T)
Input
(DC24V)
Output
(R, T)
XC3-14R-E XC3-14T-E XC3-14RT-E XC3-14R-C XC3-14T-C XC3-14RT-C 8 points 6 points
XC3-24R-E XC3-24T-E XC3-24RT-E XC3-24R-C XC3-24T-C XC3-24RT-C 14 points 10 points
XC3-32R-E XC3-32T-E XC3-32RT-E XC3-32R-C XC3-32T-C XC3-32RT-C 18 points 14 points
XC3-48R-E XC3-48T-E XC3-48RT-E XC3-48R-C XC3-48T-C XC3-48RT-C 28 points 20 points
N
P
N
Type
XC3-60R-E XC3-60T-E XC3-60RT-E XC3-60R-C XC3-60T-C XC3-60RT-C 36 points 24 points
XC3-14PR-E XC3-14PT-E XC3-14PRT-E XC3-14PR-C XC3-14PT-C XC3-14PRT-C 8 points 6 points
XC3-24PR-E XC3-24PT-E XC3-24PRT-E XC3-24PR-C XC3-24PT-C XC3-24PRT-C 14 points 10 points
XC3-32PR-E XC3-32PT-E XC3-32PRT-E XC3-32PR-C XC3-32PT-C XC3-32PRT-C 18 points 14 points
XC3-48PR-E XC3-48PT-E XC3-48PRT-E XC3-48PR-C XC3-48PT-C XC3-48PRT-C 28 points 20 points
P
N
P
Type
XC3-60PR-E XC3-60PT-E XC3-60PRT-E XC3-60PR-C XC3-60PT-C XC3-60PRT-C 36 points 24 points
XC5 series models:
Model
AC Power DC Power
Relay Output
Transistor
Output
Mix output
(R&T)
Relay Output
Transistor
Output
Mix output
(R&T)
Input
(DC24V)
Output
(R, T)
- XC5-32T-E XC5-32RT-E - XC5-32T-C XC5-32RT-C 18 points 14 points
XC5-48R-E XC5-48T-E XC5-48RT-E XC5-48R-C XC5-48T-C XC5-48RT-C 28 points 20 points
N
P
N
Type
XC5-60R-E XC5-60T-E XC5-60RT-E XC5-60R-C XC5-60T-C XC5-60RT-C 36 points 24 points
- XC5-32PT-E XC5-32PRT-E - XC5-32PT-C XC5-32PRT-C 18 points 14 points
XC5-48PR-E XC5-48PT-E XC5-48PRT-E XC5-48PR-C XC5-48PT-C XC5-48PRT-C 28 points 20 points
P
N
P
Type
XC5-60PR-E XC5-60PT-E XC5-60PRT-E XC5-60PR-C XC5-60PT-C XC5-60PRT-C 36 points 24 points
8

Thinget XC3-48R-E Specifications

General

Brand	Thinget
Model	XC3-48R-E
Category	Controller
Language	English
