Summary of XC series PLC
Unit Type ID(As register)
Max points/
Channels
Input switch quantity X X100~X137 32 points
Output switch quantity Y Y100~Y137 32 points
Input analog quantity ID ID100~ID131 16 channels
Output analog quantity QD QD100~QD131 16 channels
Expansion
1#
Module’s set value D D8250~D8259 -
Input switch quantity X X200~X237 32 points
Output switch quantity Y Y200~Y237 32 points
Input analog quantity ID ID200~ID231 16 channels
Output analog quantity QD QD200~QD231 16 channels
Expansion
2#
Module’s set value D D8260~D8269 -
Input switch quantity X X300~X337 32 points
Output switch quantity Y Y300~Y337 32 points
Input analog quantity ID ID300~ID331 16 channels
Output analog quantity QD QD300~QD331 16 channels
Expansion
3#
Module’s set value D D8270~D8279 -
Input switch quantity X X400~X437 32 points
Output switch quantity Y Y400~Y437 32 points
Input analog quantity ID ID400~ID431 16 channels
Output analog quantity QD QD400~QD431 16 channels
Expansion
4#
Module’s set value D D8280~D8289 -
Input switch quantity X X500~X537 32 points
Output switch quantity Y Y500~Y537 32 points
Input analog quantity ID ID500~ID531 16 channels
Output analog quantity QD QD500~QD531 16 channels
Expansion
5#
Module’s set value D D8290~D8299 -
Input switch quantity X X600~X637 32 points
Output switch quantity Y Y600~Y637 32 points
Input analog quantity ID ID600~ID631 16 channels
Output analog quantity QD QD600~QD631 16 channels
Expansion
6#
Module’s set value D D8300~D8309 -
Input switch quantity X X700~X737 32 points
Output switch quantity Y Y700~Y737 32 points
Input analog quantity ID ID700~ID731 16 channels
Output analog quantity QD QD700~QD731 16 channels
Expansion
7#
Module’s set value D D8310~D8319 -
Input switch quantity X X1000~X1037 32 points
Output switch quantity Y Y1000~Y1037 32 points
Input analog quantity ID ID1000~ID1031 16 channels
Output analog quantity QD QD1000~QD1031 16 channels
BD Board
Module’s set value D D8320~D8329 -
ID
Assignment
11
