ThinkPad T410 - 1200 Magnesium Structure Frame

12
Israellabel(63.5mmx19mm)
13
AnatelwirelessWANlabel(onlyforBrazil)
14
Vodafonelabel
15
ModemAMOMlabel(onlyforBrazil)
16
FCClabel
17
Informationlabel
19
Serialnumberlabel
20
Assettag
Forsomemodels,youneedtoapplytwoFCClabels.Checktheoldbasecover;ifithastwoFCClabels,
applybothtothenewbasecover.
Forthelocationofeachlabel,referthefollowinggure:
1
3
7
8
11
10
9
12
20
19
18
17
54
1415 1316
6
2
1200Magnesiumstructureframe
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage66
•“1020ExpressCardblankbezel”onpage67
•“1030SerialUltrabaySlimdeviceortravelbezel”onpage68
•“1040Harddiskdrive(HDD)andsolid-statedrive(SSD)”onpage69
•“1050DIMMslotcover”onpage70
•“1070PCIExpressMiniCardforwirelessWAN”onpage72
•“1080Keyboard”onpage74
•“1110PCIExpressMiniCardforwirelessLAN”onpage81
•“1120Keyboardbezelassembly,FPCcable,andBluethoothdaughtercard(BDC-2.1)”onpage83
•“1150Speakerassembly”onpage89
•“1160LCDunit”onpage91
•“1170Fanassembly”onpage95
104HardwareMaintenanceManual
