StepScrew(quantity)Color
Torque
1
M2×10mm,wafer-head,nylon-coated(2)
Black0.181Nm
(1.85kgf-cm)
2
M2×5mm,wafer-head,nylon-coated(1)
Black0.181Nm
(1.85kgf-cm)
3
4
Wheninstalling:Makesurethattheconnectorisattachedrmly.
2010LCDbezelassembly
Foraccess,removethisFRU:
•“1010Batterypack”onpage66
RemovalstepsofLCDbezelassembly
1
1
StepScrewcapScrew(quantity)Color
Torque
1
M2.5×6mm,wafer-head,nylon-coated(4)
Black0.392Nm
(4.0kgf-cm)
108HardwareMaintenanceManual
