Wheninstalling:Makesurethatthebezeliscorrectlyorientedasshowninthefollowinggure.
1030SerialUltrabaySlimdeviceortravelbezel
Foraccess,removethisFRU:
•“1010Batterypack”onpage66
RemovalstepsofSerialUltrabaySlimdeviceortravelbezel
Holdingthebaylocklatchintheunlockedposition1,slidethebayejectinthedirectionshownbyarrow
2,andthenpullouttheUltrabaySlimdeviceorthetravelbezelinthedirectionshownbyarrow3to
completelyremoveit4.
3
2
1
68HardwareMaintenanceManual
