ThinkPad T410 - 1160 LCD Unit Replacement

Wheninstalling:Attachthespeakerassemblyandroutethecableasshowninthefollowinggure,and
makesurethatthespeakerconnectorisattachedrmly.
1160LCDunit
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage66
•“1020ExpressCardblankbezel”onpage67
•“1050DIMMslotcover”onpage70
•“1070PCIExpressMiniCardforwirelessWAN”onpage72
•“1080Keyboard”onpage74
•“1110PCIExpressMiniCardforwirelessLAN”onpage81
•“1120Keyboardbezelassembly,FPCcable,andBluethoothdaughtercard(BDC-2.1)”onpage83
RemovalstepsofLCDunit
1
1
StepScrew(quantity)Color
Torque
1
M2.5×6mm,wafer-head,nylon-coated(2)
Black0.392Nm
(4.0kgf-cm)
Chapter8.RemovingandreplacingaFRU91
