Thinkware Q200 - 1.2 Part Names

Product overview
7
1.2 Part names
1.2.1 Front camera (main unit) - front view
DC-IN power port
Used to connect the
power cable.
GPS port
Used to connect the
external GPS receiver
(optional).
V
-IN input port
Used to connect the
rear camera (optional).
Speaker
Outputs the voice guide and buzzer
sounds to indicate the product’s status.
Front camera lens
Records the front view.
Mount connector
Used to connect the mount.
1.2.2 Front camera (main unit) - rear view
STATUS LED
Indicates the
recording status.
Wi-Fi LED
Indicates the Wi-Fi
connection status.
Memory card slot
Insert a memory card to save recordings.
Microphone
Used for voice recording.
REC button
• Short press: Starts manual recording
• Press and hold for 3 seconds: Turns the audio recording on or off.
Wi-Fi button
Press and hold for 3 seconds to connect the
product to a smartphone via Wi-Fi network.
• To format the memory card, press and hold the REC button and Wi-Fi button simultaneously for 3 seconds.
• To factory reset the product, press and hold the REC button and Wi-Fi button simultaneously for 7 seconds.
