THK KRF - 5 Structure and Model Numbers; Structure and Part Names

5-1
KRF
5. Structure and Model Numbers
5-1
Structure and part names
The name of each part of this product is shown in Fig. 3.
Housing-B cover
Housing A cover
Table cover
Table
Strip seal
Intermediate ange
Base
Motor
TLC, THC specications, without motor
Side cover
Housing-B cover
Table cover
Table
Strip seal
Cover return
Base
Motor
Side cover
Motor mounting plate
Return
Motor end cover
Table
TSC specications
Housing-B cover
Motor cover
Table cover
Strip seal
Base
Side cover
Fig. 3 Structure and part names of KRF (* KRF6 has no base. )
* For details such as the dimensions and accuracy, see the delivery specication drawings or the
catalog of Compact Series KRF.
If you have any question, contact THK.
