9.
Appendix
9-4
KRF
9. Appendix
9-7
Introduction of the grease gun unit
Grease Gun Unit MG70
The grease gun unit MG70 is capable of supplying grease for KRF by replacing the dedicated
nozzle. The grease gun has a slit window that allows you to visually check the remaining amount of
grease. Since grease is contained in a 70 g bellows cartridge, you can replace the nozzle without
soiling your hand.
Table 11 shows the specications of the grease gun, and Fig. 8 shows its appearance.
Discharge pressure 20 MPa max
Discharge rate 0.6 cm
3
/stroke
Grease 70 g bellows cartridge
Overall length 235 mm (excluding nozzle)
Weight 480 g (with nozzle, excluding grease)
Table 13 Specifications of the grease gun
