8.
Maintenance
8-14
KRF
8. Maintenance
7. Put the side covers back in place.
Model number Bolt size Tightening torque [N·cm]
KRF4 M2.6 × 4L 30
KRF5 M3 × 5L 76
KRF6 M2.6 × 5L 30
Thin head FH type head screws
8. Temporary mount a strip seal and adjust the strip seal position.
9. Adjust the strip seal position at the center of the strip seal guide and even out the clearances.
Even out the clearances
