14 MIDI implementation chart
Function Sent Received Notes
Basic Channel Default 1 ALL
Changed 1-16 1-16
Mode Default No Mode 3
Messages No No
Altered ******** No
Note Number 0 – 127 0 – 127
True voice ******** 0 – 127
Velocity Note Note ON Yes, 9nH,
v = 1 – 127
Yes, 9nH,
v = 1 – 127
Note OFF No, 9nH,
v = 0
Yes, 9nH,
v = 0 or 8nH,
v = 0 – 127
After Touch Keys No No
Channels No No
Pitch Bend Yes Yes
MIDI implementation chart
keyboard
54
