ZIP 22
Figure 1 - BASE Qty
1) Sawframe Support, revolving .......................................... 1
2) Screw TE M10x45 ..........................................................2
3) Nut M10, exagonal ......................................................... 2
4) Bearing 32007X .............................................................. 2
5) Sleeve .............................................................................. 2
6) Bushing ........................................................................... 1
7) Screw TBEI M5x16 ........................................................2
8) Nut GUK M35 ................................................................ 1
9) Splash Guard ................................................................... 1
10) Material Support, infeed ............................................... 1
11) Screw TCEI M8x25 ...................................................... 3
12) Round Plate ................................................................... 1
13) O-ring ID195X5.7W .....................................................1
14) Filter, coolant liquid ...................................................... 1
15) Tube .............................................................................. 1
16) Screw TBEI M6x20 ......................................................1
17) Connection 3/8”, coolant liquid .................................... 1
18) Electropump, coolant liquid ......................................... 1
19) Glass 3/8”, coolant liquid level ..................................... 1
20) Plug, coolant liquid drain .............................................. 1
21) Screw M10x20 .............................................................. 4
22) Washer M10 .................................................................. 4
23) Lever, Sawframe miter lock/unlock ............................ 1
24) Screw TCEI M8x25 ......................................................1
25) Washer d.18-8,5x1,6 ..................................................... 2
26) Screw TCEI M6x15 ......................................................1
27) Washer M6 .................................................................... 1
28) Nut M6, exagonal ......................................................... 1
29) Vice Support ................................................................. 1
30) Screw TBEI M6x10 ......................................................1
31) Screw TE M8x20 ..........................................................12
32) Washer M8 .................................................................... 24
33) Nut M8, exagonal ......................................................... 12
34) Pedestal ......................................................................... 1
35) Bench/Reservoir, coolant liquid ................................... 1
