ZIP 22
ELECTRIC COMPONENTS
1) Tranformer ...................................................................... TC1
2) Aux. Relay ....................................................................... KA
3) Remote Switch ................................................................. KM1
4) Fuse cartridge .................................................................. FU1
5) Fuse cartridge ................................................................. FU2
6) Blade Speed Switch.
7) Push-Button, Ready.
8) Emergency Push-Button.
