Thomas ZIP 22 - Wiring Diagrams

21
ZIP 22
Figure 3 - SAWFRAME and VICE Qty
201) Motor 0,37/0,75 kW - 50Hz - 400V – 4P 1
202) Spline 6x6x40 ...............................................................1
203) Screw TCEI M10x20 ....................................................1
204) Screw TCEI M10x25 ....................................................2
205) Plastic Cover .................................................................1
206) Screw TCEI M10x25 ....................................................4
207) Washer M10, elastic ......................................................4
208) Washer M6, elastic ........................................................4
209) Screw TE M6x20 ..........................................................4
210) Washer, large .................................................................1
211) Gear-Box G5A i=1/40 ...................................................1
212) Spline 8x7x50 ...............................................................1
213) Shaft, motor ywheel ...................................................1
214) Spline 8x7x25 ...............................................................1
215) Bearing 6208 2RS .........................................................1
216) Screw TCEI M6x15 ......................................................2
217) Connection 8x1/4" ........................................................1
218) Coolant Distributor, 3 ways ..........................................1
219) Connection 6x1/8" ........................................................4
220) Tube Ø 6 L=240 ............................................................1
221) Tube Ø 6 L=800 ............................................................1
222) Screw TBEI M5x16 ......................................................1
223) Screw TCEI M8x20 ......................................................3
224) Washer M8, elastic ........................................................3
225) Shaft, return ywheel ...................................................1
226) Screw TBEI M5x10 ......................................................2
227) Plate, blade tension .......................................................1
228) Pin Ø 5x38 ....................................................................2
229) Block, bkade tension .....................................................1
230) Screw TCEI M8x20 ......................................................3
231) Block, xed ...................................................................1
232) Support, brush ...............................................................1
233) Screw TBEI M6x10 ......................................................2
234) Brush 50-14x6, blade cleaning .....................................1
235) Nut M6, exagonal .........................................................1
236) Screw TE M6x30 ..........................................................1
237) Washer 18-6,5x1,5 ........................................................2
238) Washer 13-6,5x0,8 ........................................................2
239) Washer M10-20x2 ........................................................1
240) Screw TCEI M10x50 ....................................................1
241) Screw senza testa M8x5 ...............................................1
242) Block .............................................................................1
243) Rivet ..............................................................................1
244) Scale ..............................................................................1 continued
