Thomas ZIP 22 - Page 20

19
ZIP 22
Figure 2 - SAWFRAME Qty
101) Sawframe .................................................................... 1
103) Bar, attachment for return spring ................................ 1
104) Shaft, sawframe articulation ....................................... 1
105) Screw TCEI M10x25 ..................................................2
106) Screw TCEI M10x40 ..................................................2
107) Screw TCEI M8x30 ....................................................2
108) Screw TCEI M6x20 ....................................................4
109) Washer M6 .................................................................. 2
110) Ring Nilos 32006X AV ............................................... 2
111) Bearing 32006X .......................................................... 2
112) Flywheel, return .......................................................... 1
113) Nut GUK M30 ............................................................ 1
114) Flywheel, motor .......................................................... 1
115) Washer, Large ............................................................. 1
116) Screw TE M12x20 ...................................................... 1
117) Screw TCEI M6x10 .................................................... 2
118) Valve 1/8” ................................................................... 2
119) Block, blade tension .................................................... 2
120) Screw M6x6 ................................................................ 2
121) Screw TBEI M5x12 ....................................................2
122) Washer 12-5,5x0,8 ...................................................... 3
123) Blade Guard, blade-guide xed .................................. 1
124) Screw TBEI M6x30 ....................................................4
125) Pin, short eccentric ..................................................... 2
126) Bearing 608 2RS ......................................................... 4
127) Ring S10 ..................................................................... 4
129) Sawframe Cover ......................................................... 1
130) Washer ........................................................................ 1
131) Blade ........................................................................... 1
132) Screw M6x10 .............................................................. 4
133) Bar, mobile blade-gurad ............................................. 1
134) Screw M6x15 .............................................................. 1
135) Screw TCEI M8x20 ....................................................1
136) Block, mobile blade-guide .......................................... 1
137) Blade Guard, blade-guide mobile ............................... 1
138) Screw TBEI M6x10 ....................................................1
139) Support, electric box ................................................... 1
140) Electric Box ................................................................ 1
141) Spring, sawframe return ............................................. 1
142) Pin, spring attachment ................................................. 1
