THOMSON DPL 800VD - Parts List - Modules; Module Component Identification

To Next Page

To Previous Page

MODULES

MAIN MAIN R

35133670

AC3 AC-3 R

35133680

AMPL AMPLI R

35133690

CDM MECHANISM CONTROL R

35133730

KDB DISPLAY/CONTROL R

35133660

MPEG MPEG R

35133710

POWE POWER R

35133720

RFFI TUNER R

35133740

SMPS SMPS R

35135600

UCOM U-COM R

35133700

IC001,002 LB1641

20656300

IC100 CS492305-CL FLAT

35129170

IC101 AT27LV010A FLAT

(AC3)

35129180

IC101 KIC9164

(MAIN)

35135130

IC102 KIC9162AN

(MAIN)

35128300

IC102 TC74VHC153MX FLAT

(AC3)

35135220

IC103 TC9184AP

(MAIN)

35128170

IC103 CS8414-CS FLAT

(AC3)

35135230

IC104 AK5352 FLAT

(AC3)

35135240

IC104 TC9482N

(MAIN)

35108660

IC105,106,107 AK4393 FLAT

(AC3)

35135250

IC105 KIA7815PI

(MAIN)

35128320

IC106 KIA7915PI

35093430

IC107 IC KIA7805PI 5V

20295270

IC108,109 F/F74VHC574MX FLAT

(AC3)

35108720

IC108 KIA7905PI

(MAIN)

35108640

IC109 KIA7812PI

35096810

IC110,111,112, NJM2068DD FLAT

35109040

113,114,115,

116,117,118,

119,120,121,

122,123,124,

125,126

IC110 TC74VHC157MX FLAT

35135260

IC111 TC74VHC244MX FLAT

35108710

IC113 NJU6324M FLAT

35135660

IC114 BU4094 FLAT

35135650

IC115 BU4051BCF FLAT

35096680

IC151,152,153 NJM2296 FLAT

35128070

IC156 M35053

35135140

IC701 CXP82860-304Q FLAT

35130480

IC801 CXP82860-303Q FLAT

35134410

IC802 BU1924F FLAT

35134400

IC901 TC74HCU04M1R FLAT

35135430

RMC71 GP1U287R

20852030

PI001,002,003 RPI-574

20586840

PI004 GP2S28

20556130

Q001 KRC107M

35093030

Q101,102,103, KTC2878

35130520

104,105,106,

QV109,QV110,

QV111,QV114,

QV115,QV117

Q107,653,654, 2SC1740S/QRS/-T SMD

35105660

QV103,QV105

Q108,109,110, KRA107M

35093280

111

Q118,120,121, DTC114YS SMD

35135180

122,123,651,

901,902,903,

904

Q652,QC501, 2SA1266Y

20508210

QL501,QR501,

QS501,QS601

Q701 KTC3875S SMD

35033830

Q712,QV112, DTC114YKA SMD

35095340

QV116,QV118,

QV119,QV120

Q801 KTA1504S SMD

35096700

QC502,503,504, KTA1268GR

35093320

505,QL502,503,

504,505,QR502,

503,504,505,

QS502,503,504,

505,602,603,

604,605

QC506,507,515, KTC3200BL

20556600

QL506,507,515,

QR506,507,515,

QS506,507,515,

606,607,615

QC508,QL508, KTA1024

35108380

QR508,QS508,

608

QC509,QL509, KTC3206

35128040

QR509,QS509,

609

QC510,QL510, 2SC4137

35108350

QR510,QS510,

610

QC511,QL511, 2SD2493

35108360

QR511,QS511,

611

QC512,QL512, 2SB1624

35108370

QR512,QS512,

612

QV101,104,106, 2SA933S

35135160

107

QV102,108,113, DTA114YKA

35095350

121

D001 1N5230B 4.7V

20289370

D002 1N5232B 5.6V

20414280

D1 LTL-1C LED SMD

35108030

D101,102,103, 1N4004

11073460

104,906,907

D110,111,112, 1N4148

44009209

113,908,909,

910,911,DC501,

DC502,DL501,

DL502,DR501,

DR502,DS501,

DS502,DS601,

DS602

D2,3,4,5,6,7, KDS160 SMD

35135210

D701,801,802 RB501V SMD

35135550

D901 D15XB60

35135410

DV101,102,103, 1SS355 SMD

20726770

104,105,106,

107,108

LED72 LTL-1CHE3 LED

35095420

X001 12M288HZ

35128290

X701,801 10M0HZ

35128130

X802 4M332HZ

35134420

XV101 4M43361HZ

35135190
