Kit Installation
- Remove old the frame hinge not modified.
- Assemble the new fram hinge modified supplied with the kit (Fig.1).
- Carefully remove the disc center from the old plastic arm.
- Assemble the disc center on the new plastic arm modified supplied with the kit (Fig. 2).
- Set the assembly.
(Fig. 1)
(Fig. 2)
New fram hinge modified
supplied with the kit.
IRIS Code : The code mentioned below must be used to report the failure on the warrantee claims form;
we have included it to make fault report easier and the data more reliable.
R.Code
D.Code
Section
Position
Qty
Part code number
Symptom
9750
3558 01 HR A1 A
T
3312
You do not need to write anything in the white boxes.
2
