THOMSON DTH175EL - Page 41

THOMSON DTH175EL Service Manual
NO. PART NO. DESCRIPTION QTY LOCATION
24 M2D10FR104220000 FR104
（
DO-41
）
3 D101,,D103,D907
25 M2D1IN5392220000 1N5392-
（
DO-41
）
2 D108,D109
26 M2D1IN5822220000 IN5822 1 D105
Certain VOLT Diode
27 M2D1BZX12V220000 BZX-12V-1/2W-
（
DO-35
）
1 Z101,
29 M2D1BZX4V3220000 BZX-4V3-1/2W-
（
DO-35
）
1 Z901
Inductor
30 M2H20000L0710000 L-071 1 D106
31 M2H4LGA10UHK0307 LGA0307-10uH-K 2 L103,R106
32 M2H20BC202290000 BC20229 1 LF901
IC
33 M2IFSDL016500100 FSDL0165 1 U901
34 M2I00PC817B00000 PC817B-DIP4 1 U902
Insurance Managing
35 M2U110T0A5250V00 T0.5A 250V 1 F901
Insurance Managing Header
36
M2P3300000520000
5*20 2 F901
Transformer
37 M2T11EEL221001E0 EEL22-1001E 1 TR901
Jack
38 M2P2200000VH3000 VH-3 1 CN901
M2P220000VH3B000 VH-3-B 1 SW901(SWITCH SW901
）
39 M2P000000PH5A000 PH-5A 1 CON1
40 M2P000TJC35AB000 TJC3-5A-B 1 CON2
Jump Wire
41 *************** J--10mm 5 JP1,JP4,JP6,R907,D107
42 *************** J--8mm 3 JP9,JP10,SW901(STB 4.5W SW901)
43 *************** J-18mm 1 JP5
Ground Slice
44 M2A00GDP31400001 GDP-314 2 GDP1 GDP2
PCB
45 M2B0HY338PN0412C HY338-0265-09C V2.0 P/N:0412C 1 PCB
****** 20050122
