THOMSON DTH175EL - MPEG Parts List

THOMSON DTH175EL Service Manual
MEPG Parts List
NO. PART NO. DESCRIPTION QTY LOCATION
Chip Resistor
1 M2R0000030811000 RC-05K000OT 2 L3,L10
2 M2R001R030811000 RC-05K1R0JT 4 R42~R45
3 M2R0033030811000 RC-05K330JT 1 R82
4
M2R0000031000000 RC-03K000OT 24 R11,R20,R21,R26~R31,R40,R79,R80,
R89,R90,R103,R104,R114,R134
R172,R171,R169,R112,R9,R161
4** M2R0000031000000 RC-03K000OT 1 R61 16M FLASH
5 M2R001R031000000
RC-03K1R0JT 1 R22
6 M2R006R831000000
RC-03K6R8JT 1 R92
7 M2R0010031000000
RC-03K100JT 5 R23,R24,R39,R41,R126
8 M2R0022031000000
RC-03K220JT 1 R168
9 M2R0033031000000
RC-03K330JT 7 R63~R66,R105,R139,R142
10 M2R0075031000000
RC-03K750JT 2 R100,R160
11
M2R0075021000000 RC
－
03K750FT 6 R73,R75,R81,R84,R91,R94
12 M2R0010131000000
RC-03K101JT 1 R159
13 M2R0011131000000
RC-03K111JT 1 R162
14 M2R0030121000000
RC-03K301FT 1 R60
15 M2R0033131000000
RC-03K331JT 1 R175
16 M2R0047131000000
RC-03K471JT 5 R108,R193,R194,R197,R198
17
M2R0056131000000 RC-03K561JT 1 R25
18 M2R0068121000000
RC-03K681FT 4 R59,R68,R69,R98
19
M2R0091031000000 RC-03K910JT 1 R214
20 M2R0010231000000
RC-03K102JT 19 R117,R129,R137,R149,R155,R165,R99
R179,R181,R183,R185,R187,R189
R6,R48,R199,R200,R74,R176(Karaoke)
21 M2R0022231000000
RC-03K222JT 3 R101,R102,R107
22 M2R0027231000000
RC-03K272JT 1 R122
23
M2R0039231000000 RC-03K392JT 2 R202,R204(Karaoke)
24 M2R0047231000000
RC-03K472JT 4 R106,R121,R173,R72(Karaoke)
25 M2R0051231000000
RC-03K512JT 6 R116,R128,R136,R148,R154,R164
26 M2R0082231000000
RC-03K822JT 2 R201,R203(Karaoke)
27 M2R0010331000000
RC-03K103JT 25 R1,R33,R34,R50,R52,R54,R55,R58
R70,R113,R124,R57,R191,R192,R195
R196,R212,R115,R127,R135,R147
R163,R2,R153,R67
