THOMSON DTH175EL - Page 43

THOMSON DTH175EL Service Manual
NO. PART NO. DESCRIPTION QTY LOCATION
28 M2R0015331000000 RC-03K153JT 2 R14,R49
29 M2R0018331000000 RC-03K183JT 1 R47
30 M2R0020331000000 RC-03K203JT 4 R46,R51,R53,R56
31
M2R0022331000000
RC-03K223JT 6 R110,R123,R132,R146,R152,R158
32 M2R0010431000000 RC-03K104JT 18 R7,R16,R32,R35,R111,R125,R119
R131,R141,R151,R157,R167,R178
R182,R184,R186,R188,R180
33 M2R0015431000000 RC-03K154JT 2 R17,R19
34 M2R0018431000000
RC-03K184JT 6 R118,R130,R140,R150,R156,R166
35 M2R0068431000000 RC-03K684JT 2 R10,R15
36
M2R0075431000000 RC-03K754JT 1 R3
Metal Oxidation Resistor
37
M2R0075030811000
RC-05K750JT 2 R96,R213
Resistor Array
38 M2R9933031099004
RCML16W330JT
2RN1,RN2
Chip Capacitor
39 M2C0100F30060300 CC-0603CG100JN500T 6 C59,C61,C63,C65,C67,C69
40 M2C0200F30060300 CC-0603CG200J500NT 3 C4,C10,C11
41 M2C0220F30060300 CC-0603CG220J500NT 12 C85~C88,C77~C84
42
M2C0270F30060300
CC-0603CG270J500NT 1 C73
43
M2C0470F30060300
CC-0603CG470J500NT 14 C47~C58,C75,C76
44 M2C0101F30060300 CC-0603CG101J500NT 3 C22,C70,C71
45 M2C0121F30060300 CC-0603CG121J500NT 1 C28
46 M2C0151F30060300 CC-0603CG151J500NT 2 C41,C42
47 M2C0331F30060300 CC-0603CG331J500NT 2 C37,C38
48 M2C0391F30060300 CC-0603CG391J500NT 3 C1,C89,C90
49 M2C0102F44060300 CC-0603B102K500NT 3 C5,C6,
C44
50 M2C0152F44060300 CC-0603B152K500NT 1 C35
51 M2C0222F44060300 CC-0603B222K500NT 2 C3,C74
52 M2C0332F44060300 CC-0603B332K500NT 6 C60,C62,C64,C66,C68,C72
53 M2C0153F54060300 CC-0603F153M500NT 1 C40
54 M2C0333F54060300 CC-0603F333M500NT 1 C14
55 M2C0473F54060300 CC-0603F473M500NT 2 C17,C18
56 M2C0104F84060300 CC-0603F104Z500NT 87 CB1,CB2,CB4~CB8,CB10,CB12~CB37
CB38,CB9,CB11,CB40,CB42~CB43
CB50~CB55,CB57~CB63,CB65,CB67
CB77~CB82,C7~C9,C12,C13
C21,C29,C30,C33,C34,C36,C39
