THOMSON DTH175EL - Page 44

THOMSON DTH175EL Service Manual
NO. PART NO. DESCRIPTION QTY LOCATION
C43,C46,CB83,CB68,CB71,CB85
CB84,CB64,CB66,CB69 CB72~CB76
57 M2C0474B84080500 CC-0805F474Z160NT 1 C19
58 M2C0105B84060300 CC-0603F105Z160NT 6 C15,C16,C23~C26
ELECT Capacitor
59 M2C2106B57051122 CD11-16V-10U-M 11 CE40,CE44,CE46,CE48,CE49,CE51
CE53,CE1,CE15,CE24,CE55
60 M2C2476B89051122 CD11-16V-47U-M 11 CE7,CE16~CE18,CE21~CE23,CE27
CE28,CE33,CE37
61 M2C2107B57051122 CD11-16V-100U-M 4 CE19,CE20,CE3,CE11
62 M2C2227B59061222 CD11-16V-220U-M 12 CE2,CE4~CE6,CE9,CE42,CE43,CE25
CE12~CE14 ,CE26
63 M2C2477C57631222 CD11-10V-470UF-M
（
6.3*12
）
1CE38
Color loop Inductor
64 M2H4LGA10UHK0307
LGA0307--10UH-K
2 L21,L22
65 M2HL018U500A0805
L0805-1.8uH-500mA
7 L28,L32,L29,L33,L34,L35,L43
Chip Inductor
66 M2H0500M02U70805 L0805-2.7UH-500MA-K 1 L42
Chip Magnetism Bead
67 M2HL500M070R0805 L0805-500mA-70R 12 L2,L4,L5,L7~L9,L11,L19,L20,L25 ,L30
L26
L27
68 M2HL500M600R0603
L0603-500mA-600R 13 L12~L16,L18,L23,L44~L49
Chip Diode
69 M2D0IN4148110000
IN4148(LL-34)
18 D3,D4,D6,D8,D10,D19~D21,D12,D14
D5,D7,D9,D11,D13,D15,D22,D23
VOLT REG Diode
70 M2D1HZ5C20000000 HZ5C2
1D17
71 M2D1BZX9V1220000
BZX-9V1-1/2W(DO-35) 1 D18
Chip Transistor
72 M2Q02SK301800000
2SK3018
（
SOT23
）
2Q2,Q3
73
M2Q002N390400000 2N3904S(SOT-23)
9 Q1,Q14,Q15Q19,Q21~Q25
74 M2Q00BT390600000 BT3906 (SOT23) 4 Q20,Q12,Q16,Q26
75 M2Q000A101500000
2SA1015-(SOT-23)
2 Q17,Q18,
76 M2Q000D130400000 KTD1304-(SOT-23) 1 Q34(Karaoke)
77 M2Q100A101502200
2SA1015-(TO-92) 1
Q27(Karaoke)
Transistor
77 M2Q100S8550D2200
S8550D-(TO-92) 4 Q4,Q5,Q28Q29
78 M2Q100S8050D2200
S8050D-(TO-92) 2
Q30,Q31
