NO. PART NO. DESCRIPTION QTY LOCATION
Jack
79 M2P88FPC24005000 JP24-05M 1
HA1
80 M2P000000PH5A000
PH-5A 1 J4
81 M2P000000PH6A000 PH-6A
1J1
82 M2P00000PH6AB000 PH-6A-B
1J2
83 M2P0000TJC35A000 TJC3-5A
1CON1
84 M2P11AV684120003 AV6-8.4-12-03 1 CN8
85 M2P11000RCA1A000 RCA-1A-COAX 1 P4
86 M2P00000PH10A000
PH-10A 1 J5
87 M2P00000PH7AB000
PH-7A-B 1 J7
88 M2P000000PH8A000 PH-8A
1 J9(Karaoke)
89 M2P660000S4KB000 S-4KB
1P1
90 M2IDLT1131A00000 DLT1131A
1P3
M2I0GP1F32T00100 GP1F553TZ/554TZ
1P3
Crystal
91 M2L1127M00003000
27MHz±30PPM-THIRD-20Pf
1Y1
Crystal Mat
92 M2IAZ11170000000
AZ1117H-ADJ-SOT223
1 U1
93 M2IAZ1117H330000
AZ1117-3.3V-SOT223
1
U2
94 M2I000D595400000 D5954FP 1
U5
M2I00AT565400000 AT5654 1 U5
95 M2I0AT24C0200000
AT24C02-SSOP8
1
U12
96 M2I0MT1389FE0000 MT1389FE-C-LQFP256A 1
U4
M2IEM8165TS00000 EM636165TS-6
2
U7 ,U8
M2IEM636165TS000 EM636165TS-7
2
U7 ,U8
M2IM12L16161A000 M12L16161A-7T 2
U7 ,U8
97
M2IVT36171600000 VT361716T-6AA 2
U7 ,U8
M2IVT36171600001 VT361716T-6AA(FA) 2
U7 ,U8
M2ITM50S11600000 TM50S116T-7 2
U7 ,U8
M2ITM50S11600060
TM50S116T-6 2
U7 ,U8
98 M2IM12L64164A000
M12L64164A-TSOP54 1
U9 Choose one(when don't use U7, U8)
99 M2I0V64162000000
HY57V641620HG T-6,TSOP54
1 U9 Choose one(when don't use U7, U8)
M2IAT49BV162A000
AT49BV162A-TSOP(16M,5V)
1U11
M2I29LV160700000
MX29LV160ABTC
－
70
－
TSOP
1U11
M2IMX29LV160ATT1
MX29LV160ATTI
－
70
－
TSOP
1U11
M2IM29LV160TE000
MBM29LV160TE-70-TSOP
1U11
M2I29LV160BTC000
MX29LV1600BBTC
1U11
100
M2I039VF08800000 SST39VF088-70-4C-EK 1 U11
M2IS29AL00800002
S29LV008D70TA102-TSOP48
1
U11
