Technical Specication ELECTRAK LL
Input voltage [Vac] 24
Input voltage tolerance [Vdc] 16.8 - 32
Stroke length [mm] see product label
Static load at fully retracted (Fx), maximum [kN (lbs)] 18 (4050)
Dynamic load (Fx), maximum [N] see product label
Speed (constant speed regardless of load)
LLxx-B040
LLxx-B060
[mm/s (inch/s)]
30 (1.18)
15 (0.59)
Current draw @ rated max. load [A] see product label
Weight
(1)
[kg]
(stroke [mm] × 0.006) + 7
End play, maximum [mm (in)]
1.2 (0.047)
Operating temperature limits, standard units [°C (°F)]
- 40 to + 85 (- 40 to + 185)
Full load duty cycle @ 25 °C [%] see product label
Restraining torque [Nm (lbf-in)] 0 (internally restrained)
Motor cable lead cross section [mm
2
(AWG)] 1.5 (16)
Signal cable lead cross section [mm
2
(AWG)] 0.5 (20)
Cable length [mm (in)] 0.3 (11.8)
Protection class - static IP66 / IP69K
Protection class - dynamic IP66
Safety features
static load holding brake
internal end-of-stroke limit switches
overload protection
temperature monitoring
temperature compensation
voltage monitoring
yes
yes
yes
yes
yes
yes
Compliances CE, RoHS, EN 50155,EN 60077, EN 45545
7. Technical specications
7.1 Technical data
(1) Conversion factor for kilogram to pound: 1 kg = 2.204623 lbs
