174
The “quick coupler” is directly connected to the RV propane system. The “quick-coupler”
connection has a positive shut-o valve as required by code and standards.
1. Place the “quick coupler handle in the
OFF position and push back the sleeve.
The valve handle must be OFF to make
the connection.
2. Insert the plug and release the sleeve
3. Push the plug until the sleeve snaps for-
ward, locking the plug into the socket.
4. Turn the handle ON to allow propane to ow to the drop in stove.
Your recreational vehicle may be equipped with an exterior
refrigerator in the front storage compartment, or in the out-
side kitchen (if so equipped). For information on use and
safety, refer to the manufacturer’s user guide.
The outside kitchen may include an LP fueled BBQ grill.
This grill is mounted in a pull out drawer. It has a single
burner control. It attaches to the LP tank using a quick
coupler connection as described above.
The drip pan attaches to tabs underneath the grill at
each end. A handle is mounted in the middle of the drip
pan to dump the contents. Refer to the grill user manual
for further information.
This grill is only available on certain RV models.
Outdoor cooking warning label
should not be removed from the RV.
A drip pan is included with the grill. The drip pan be used
underneath the grill to catch hot grease and liquids dripping from the grill
and to prevent injury.
