73
1. Level the unit.
2. Main Power switch at stepwell (locations may vary) must be ON.
3. Verify the battery is fully charged and hooked up to the electrical system.
4. Remove the transit bars (if so equipped) if extending the slideout, and install them if
retracting the room for travel.
5. Press and hold the IN/OUT switch in the OUT position
until the room is fully extended and stops moving. Hold
the switch in the IN position to retract the room.
6. Release the switch, which will lock the room into posi-
tion. If the slideout switch is held after the room is fully
extended or retracted, the control will sense that the room
has stopped and will shut the motor o after a few seconds.
Locate the crank extension under the inside of the frame (). Attach a standard
fth wheel landing gear crank handle, a ¾” socket and ratchet, or drill and nut driver.
Rotate the extension clockwise to retract the slideout and counterclockwise to extend it.
attempt to disengage the motor as the actuator is “manual ready”.
Install transit bars (if so equipped) on the slideout room during
storage and transportation.
For long-term storage it is recommend the room be closed
(retracted).
Always disconnect battery from system prior to manually operating
system. Failure to disconnect battery can cause electricity to back feed
through the motor and cause serious damage to the system as well as void
the warranty
. The gears can be stripped out if the
room is manually retracted/extended to its fullest extent and the operator
continues to rotate manual override. Damage can also occur to the slide
components, slide room structure or trim components. Damages due to
misuse of the manual override feature will void any and all claims to the
Limited Warranty.
