LDC401 & LDC401A Automated Cleavers Chapter 4: Set-up
Rev B, July 19, 2017 Page 7
5. The other USB cable has one end that is USB
Type A. Plug that end of that cable into the USB
socket of the tablet.
6. Plug the USB Type B plug into its socket on the
back of the unit.
7. Plug the USB Type A plug (on the first USB
cable) into its socket on the back of the unit.
4.2. Power-Up
1. Turn on the Cleaver using the ON/OFF Rocker Switch located on the back of the unit.
2. Turn on the Tablet Controller (press and hold the Power Button).
4.3. Shut-Down
Turn off the Cleaver using the on/off Rocker Switch located on the back of the Cleaver.
