Page #55 background image
LDC401 & LDC401A Automated Cleavers Chapter 11: Specifications
Rev B, July 19, 2017 Page 51
Chapter 11 Specifications
Item # LDC401 LDC401A
Cleave Type
Flat Cleave
Flat Cleave
Angled
13
Cleave up to 15°
Accepted Fiber Sizes
Cladding: Ø80 µm to Ø1.25 mm
Buffer: Ø80 µm to Ø3.198 mm
Accepted Fiber Types
SM, PM, MM, Specialty Fibers Including
Photonic Crystal Fiber (PCF) and Non-Circular Fiber, Capillary Tubes
Cleave Method
Tension and Scribe
Cleave Tolerance
±0.5°
±0.5° (Flat)
±1.0° (Angled)
Rotation Stage
N/A
0.1° Resolution,
Stepper Motor Controlled
Loading
Linear Tension, Stepper Motor Controlled
Tension
63.7 N (14.3 lbs) Max, Programmable
14
Scribe
Diamond Blade, Stepper Motor Controlled
Fiber Holding Blocks
Internal Vacuum Pump for Easier Loading,
Up to 9 inHg (4.4 psi) of Pressure
V-Groove Inserts
Available Separately Below
Power
12.5 VDC, 5 A (Provided by External Power Supply)
External Power Supply
100 - 120 / 200 - 240 VAC, 4.5 / 2.2 A, 47 - 63 Hz
Dimension (L x W x H)
without Holding Blocks or
Rotation Stage
10.14" x 5.30" x 5.15"
(257.4 mm x 134.6 mm x 130.7 mm)
Dimensions (L x W x H)
10.14" x 5.30" x 6.82"
(257.4 mm x 134.6 mm x 173.3 mm)
10.14" x 5.30" x 6.96"
(257.4 mm x 134.6 mm x 176.8 mm)
Weight
10.0 lbs (4.5 kg)
13
It may not be possible to create clean angled cleaves in specialty fibers with large "air-fill" fractions due to the structural properties of the
fiber.
14
These Cleavers are calibrated using standard weights, so the tension settings are programmed into the Tablet Controller in grams. This
maximum tension corresponds to 6.5 kg.
