power immediately.
15. LED lamp
It’s used for lighting the working table once turn the Main switch on.
16. Laser power switch
The laser power will be on while you turn it on
17. Main power switch
The laser machine will be start while you turn it on
18. Ethernet port
This Ethernet port is for connecting computer.
19. U-disk connection port(USB)
You can save the file as a U-disk File by press “SaveToUFile” on the software, then
save it to the u-disk and insert the u-disk to the port of laser machine, then use the
control panel to select and control it to work
20. PC connection port(USB)
This USB is for connecting computer.
21. Right side door
There are laser controller, driver(Hybrid Servo Drive and Micro Stepper Drive ), power
supplier (both 24v DC and 36vDC), the main connecting cables and cooling fan here,
please open this door for checking these parts, but must pay attention to the electric
current. if you need to repair, please contact with professional maintenance staff.
22. Right-up side door
Maintenance for the Emergency stop button if required
This door is locked by using outside locks.
23. Indicate light
The light is always keeping green color while the laser does not work or working but
the lid is closed.
The light will turns to red color while the lid/cover is opened during working.
24. Laser supply socket
To connect the main power and the extend power according the label information. And
in the main power socket have the fuses.
25. Laser tube cover
There are installed the laser tube, red dot pointer device, beam combiner and the first
