 U Move: When the green block is on “U Move” item, to control the rotary
attachment to turn by pressing left and right arrow button.
 Axis Reset+: When the green block is on this item, you can manually reset the
axis if needed.
 Set default para: To recover all manufacturer parameters and user parameters
for your machine
 Auto Focus: To use the auto focus function.
 Language: The item “Language” helps you to select a appropriate langue which
is displayed on the panel:
 IP Setup: The machine is already assigned an IP address as
192.168.1.100,and the IP address on software should be the same while
communicate
 Diagnoses: the “Diagnoses” interface shows some system input information,
such as limiter status, the status of the water protecting, and the status of the
door protection etc..
4.4.7 File button
1). Memory File
On the main interface, if “File” button is pressed, it will show as below:
File：
Speed：
MaxPow：
01
300mm/s
30.0%/30.0%
X：
Y：
Z：
150.2
153.5
3000
mm
mm
mm
01 400
02 200
03 100
File： Count：
Udisk+
Other+
Run
Track
Work time
Clear count
Delete
Copy to udisk
Read mem file
Idle 00.00.00 Count: 99 X: 180.5 mm Y: 235.6 mm connect
When showing this menu, the system would read the memory file firstly, the file name and
the work times would be listed in the area, and the selected file is previewed in the bottom
right area. “Y+/-” keys could be used to move the cursor on the file name list. When the
cursor is on a target file name, presses the “Enter” key, the selected file will be previewed
on the main interface, and then if “Esc” key is pushed, the preview will disappear.
“X+/-” keys could be used to move the cursor left and right. All the item show as below:
 Read mem file: read the memory file list;
 Udisk: read the U disk file list;
