28
39
VBAT
41
GND
43
GPIO_X
CAM5_RST_N
45
GPIO_Y
CAM4_PWDN
PIN
C865 Dev Kit Signal
Additional Info
2
GPIO_Z
CAM4_RST_N
4
CAN_H
6
CAN_L
8
VREG_IO_1P8
10
GND
12
PM_GPIO-A
PM8150L GPIO6
14
PM_GPIO-B
PM8150L GPIO10
16
GPIO-M/QUP-B0
QUP9
18
GPIO-N/QUP-B1
QUP9
20
GPIO-O/QUP-B2
QUP9/PWM
22
GPIO-P/QUP-B3
QUP9/BOOT_CONFIG 0
24
GPIO-Q
GPIO 147
26
GPIO-R
GPIO 148
28
GPIO-S
GPIO 148
30
GPIO-T
GPIO 149
33
PM_AMUX1
PM8150L
34
PM_AMUX2
PM8150L
36
BATT_THERM
38
BATT_ID
