5.3 Tertiary High Speed Connector: HS3
PIN
C865 DEV KIT Signals
Note
1
CSI4_C_P
3
CSI4_C_M
5
CSI4_D0_P
7
CSI4_D0_M
9
GND
11
CSI4_D1_P
13
CSI4_D1_M
15
CSI4_D2_P
17
CSI4_D2_M
19
CSI4_D3_P
21
CSI4_D3_M
23
GND
25
CSI3_D2_P
27
CSI3_D2_M
29
CSI3_D3_P
31
CSI3_D3_M
33
GND
35
CSI5_C_P
37
CSI5_C_M
39
CSI5_D0_P
41
CSI5_D0_M
43
CSI5_D1_P
45
CSI5_D1_M
