 HS2:1 x 60 pin high-speed connector (4L-MIPI CSI x 2, SPI x 1, PCIe 3.0 gen3
1L, USB 3.0 x1, GPIO x 8)
 HS3:1 x 60 pin high-speed connector (4L-MIPI CSI x 2, 4L-MIPI CSI x1(plus
2L CSI in HS1), RF CLK x 2, 2L-PCIe 3.0 x 1, 2L-PCIe 3.0 x 1 (plus PCIe 1L
in HS2), 4L-MIPI DSI x 1)
 LS1:1 x 96boards 40 pin low-speed connector (UART x 2, SPI, I2S/PCM, I2C
x 2, GPIO x 12, DC powers)
 LS2:1 x 96boards 40 pin low-speed connector (Speaker x 2, DMIC I/F x 3, CAN,
I2S, GPIOs, PWM, ADC, I2C, DC powers)
 LS3:1 x 96boards 40 pin Low-Speed connector (SPI x 2, SSC I2C, sensor
interrupt x 5, GPIOs, RTC clock, DC powers)
Other Interfaces
 2 x SIM holders
 1 x M.2 key B connector
 8 x RF Connectors
 4 B2B connectors
Cellular Components
10.2.2 Board views
Top view
TBD
