33
10
QCA_GPIO-E
12
GPIO-VV
14
GPIO-WW
16
SPI3_MISO
SSC QUP5
18
SPI3_MOSI
SSC QUP5
20
SPI3_CLK
SSC QUP5
22
SPI3_CS
SSC QUP5
24
PS_INT
26
ACCEL_INT
28
GYRO_INT
30
MAG_INT
32
MAG_DRDY_INT
34
I2C4_SDA
SSC QUP0
36
I2C4_SCL
SSC QUP0
38
VREG_L5C_1P8
40
GND
42
GND
44
SPI3_CS2
SSC QUP5
46
GPIO-XX
SSC QUP4
4.3.1 SSC SPI
C865 DEV KIT implements 2 SSC SPI interfaces for different sensors that connect to SM8250
processor sensor core. Each SPIs can support 2 CS signals.
The signals are:
 SPI2_CLK_LS3: Connects to SSC QUP2 of SM8250 SoC, to be configured to CLK.
 SPI2_MOSI_LS3: Connects to SSC QUP2 of SM8250 SoC, to be configured to MOSI.
 SPI2_MISO_LS3: Connects to SSC QUP2 of SM8250 SoC, to be configured to MISO.
