Thundercomm TurboX C865 Dev Kit - Getting Started; Required Equipment; OS Startup Process

`www.thundercomm.com.
12
2 Start the board
2.1 Required equipment
Equipment
Description
TurboX C865 DEV KIT
development board
 C865 SOM based on the Qualcomm® SM8250 processor
 C865 Main IO board based on 96board requirement
Power adapter
 12 V with 2500 mA required per 96Boards specification
USB to Micro USB
cable
 For serial console interface and ADB, Fastboot commands
USB to USB Type C
cable
 For connecting the USB3.0 Type C port and flashing images
Host PC
 For connecting the board and installing Fastboot
2.2 OS startup process
Display is not supported in the LE OS.
1. Open the serial console tool on host PC (for example: minicom).
2. Turn on SW2 on the Dip Switch#1 (see section 1.2.2, #16) to enable the USB2.0 debug port (see
Section 1.2.2, #21).
3. Turn on SW3 on the Dip Switch#1 (see section 1.2.2, #16) to enable the auto power up on (along
with power connector).
