DSI0_D2_M_HS1
43
GND
45
DSI0_D3_P_HS1
47
DSI0_D3_M_HS1
49
GND
51
USB1_HS_DP_HS1
53
USB1_HS_DM_HS1
55
GND
57
NC
59
NC
PIN
C865 Dev Kit Signals
Note
2
CSI0_C_P
4
CSI0_C_M
6
GND
8
CSI0_D0_P
10
CSI0_D0_M
12
GND
14
CSI0_D1_P
16
CSI0_D1_M
18
GND
20
CSI0_D2_P
22
CSI0_D2_M
24
GND
