5 Communication
5.1 The Serial Interface Of The Device
The display and control unit is equipped with serial interfaces RS232 and USB.
Via device address 100 settings for the VD12 / VD14 can be made. Device ad-
dress 1 to 4 enable direct access to the connected transducers and their
parameters, e.g. for the query of measurement values.
Communication telegrams are transmitted as ASCII text according to the Thy-
racont protocol version V2. Detailed information is provided in the separate
description "Thyracont Communication Protocol".
Download link: www.thyracont-vacuum.com/download-center/
Interface-Parameter:
9,6 kBd, 8 data bits, 1 Stopbit, no parity
5.2 Survey of Commands
Command
Code
Type of Device TD
Product Name PN
Version Device VD
Version Firmware
VF
Version Bootloader VB
Device Restart
DR
Display Unit
DU
Panel Status
PS
Controller Status
CS
Relay 1 … 4 R1…R4
The previous communication protocol version V1 will further-
more be supported! Therefore all telegrams built according to
protocol version 1 can further be used.
