7 Technical Data
Display
LCD graphic display, with background illumination,
51 x 31 mm, resolution 128 x 64
Display Refresh Rate
2 Hz (0,5 s)
Scanning Rate
VD12S2: RS485: 12,5 Hz (80 ms)
0-10V: 50 Hz (20 ms)
VD14S4: RS485: 6,25 Hz (160 ms)
Voltage Supply
95 – 265 VAC, 50/60 Hz
Power Consumption
VD12S2: max. 25 W including transducers
VD14S4: max. 45 W including transducers
Ambient Temperature
5...50
o
C
Storage Temperature
-20...+60
o
C
Measuring Input
1 x RS485, SubD, 15pin, male, for Smartline
VD12S2 only: 2 x 0 - 10V Amphenol C91E, 6pin, female
Switching Output
2 x relay, change-over type, SP assignable (VD14S4: 2x2)
Phoenix strip terminal 6-pin (VD14S4: 2x)
lifetime > 300.000 cycles,
4 A / 250 VAC, 2 A / 45 VDC
Serial Interface
Mini-USB socket, Type B, 5pin (Virtual Com Port)
RS232: 3.5 mm jack, 3-pole
Protection Class
IP 20
Weight
750 g
