TECHNICAL DATA
14
NA30 - Manual - 04 - 2022
 Certifications
Reference standards
Product standard for measuring relays EN 50263
CE Conformity
• EMC Directive
2014/30/EC
• Low Voltage Directive 2014/35/EC
Type tests IEC 60255-6
3.2 INPUT CIRCUITS
 Auxiliary power supply Uaux
Voltage
Nominal value (range) 24...48 V~/-
115...230 V~/110...220 V-
Operative range (each one of the above nominal values) 19...60 V~/-
85...265 V~/75...300 V-
Inrush current (max)
• 24 V- 6 A, 5 ms
• 48 V- 14 A, 5 ms
• 110 V- 20 A, 1 ms
• 230 V~ 50 A, 1 ms
Frequency (for alternate voltage supply) 45...66 Hz
Max distortion factor ( for alternating voltage supply) 15%
Max alternating component (for dc voltage supply):
• Full wave rectified sine wave 100 %
• Sine wave 80 %
Power consumption:
• Maximum (energized relays, Ethernet TX) 10 W (20 VA)
• Maximum (energized relays, Ethernet FX) 15 W (25 VA)
 Phase current input circuits
Relay nominal phase current I
n
1 A or 5 A selectable by dip-switch
Permanent overload 25 A
Thermal overload (1 s) 500 A
Dynamic overload (half cycle) 1250 A
Rated consumption (for any phase) ≤ 0.002 VA with I
n
=1 A
≤ 0.04 VA with I
n
=5 A
 Residual current input circuit
Relay nominal residual current I
En
1 A or 5 A selectable by dip-switch
Permanent overload 25 A
Thermal overload (1 s) 500 A
Dynamic overload (half cycle) 1250 A
Rated consumption ≤ 0.006 VA with I
En
=1 A
≤ 0.12 VA with I
En
=5 A
 Residual voltage input circuit
Relay residual nominal voltage U
En
50...130 V
Permanent overload 130 V
Thermal overload (1 s) 200 V
Rated consumption ≤ 0.5 VA
 Binary input circuits
Quantity 5
Type optocoupler
Operative range 24...265 V~/-
Min activation voltage U
DIGmin
18 V
Max consumption, energized I
DIG
3 mA
 Block input (Logic selectivity)
Quantity 1
Type polarized wet input (powered by internal isolated supply)
Max consumption, energized 5 mA
3.3 OUTPUT CIRCUITS
 Relays
Quantity 6
Type of contacts K1, K2 changeover (SPDT, type C)
Type of contacts K3, K4, K5 make (SPST-NO, type A)
Type of contacts K6 break (SPST-NC, type B)
