APPENDIX
193
NA30 - Manual - 04 - 2022
8.8 APPENDIX D - Setting table
Description Parameter Unit Setting range
Note The temperature (26 element), output relay K7...K10, L6...L10 LEDs and binary input IN6...IN42 settings are available only when the concerning
I/O circuits are implemented (MPT, MRI and MID16 modules on Thybus)
Set
Base
Relay reference name
Relay nominal frequency - fn Hz 50 ... 60 step = 10
Relay phase nominal current - In 1 A | 5 A
Relay residual nominal current - IEn 1 A | 5 A
Relay residual nominal voltage ( direct measurement ) - UEn V 50 ... 130 step = 1
Phase CT primary nominal current - Inp A
1 ... 499 step = 1
500 ... 4990 step = 10
5000 ... 10000 step = 100
Residual CT primary nominal current - IEnp A
1 ... 499 step = 1
500 ... 4990 step = 10
5000 ... 10000 step = 100
Residual primary nominal voltage ( phase to phase ) * 1.73
- UEnp
V
50 ... 499 step = 1
500 ... 4990 step = 10
5000 ... 49900 step = 100
50000 ... 500000 step = 1000
Measurements reading mode RELATIVE | PRIMARY
Language English | Turkish | Russian
Inputs
Binary input IN1
IN1
Logic Active-ON | Active-OFF
IN1 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN1 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN1 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN2
IN2
Logic Active-ON | Active-OFF
IN2 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN2 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN2 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN3
IN3
Logic Active-ON | Active-OFF
IN3 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN3 tOFF
