Thytronic NA30 User Manual

APPENDIX
194
NA30 - Manual - 04 - 2022
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN3 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN4
IN4
Logic Active-ON | Active-OFF
IN4 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN4 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN4 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN5
IN5
Logic Active-ON | Active-OFF
IN5 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN5 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN5 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN6
IN6
Logic Active-ON | Active-OFF
IN6 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN6 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN6 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN7
IN7
Logic Active-ON | Active-OFF
IN7 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN7 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
