Thytronic NA30

APPENDIX
230
NA30 - Manual - 04 - 2022
BF Enable BF Enable OFF | ON
BF Phase current threshold
State OFF | ON
Pickup value In 0.05 ... 1.00 step = 0.01
BF Residual current threshold
State OFF | ON
Pickup value IEn 0.01 ... 2.00 step = 0.01
BF Time delay
Value s 0.06 ... 10.00 step = 0.01
BF Logical block BF-BLK1 OFF | ON
BF Start from circuit breaker CB Input OFF | ON
BF Start relays BF-ST-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
BF Trip relays BF-TR-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
BF Start LEDs BF-ST-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
BF Trip LEDs BF-TR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
PLC
Setpoints
Enable PLC Enable OFF | ON
Relays PLC-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
LEDs PLC-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Switches
Switch 1 0 | 1
Switch 2 0 | 1
Switch 3 0 | 1
Switch 4 0 | 1
Switch 5 0 | 1
Switch 6 0 | 1
Switch 7 0 | 1
Switch 8 0 | 1
Switch 9 0 | 1
Switch 10 0 | 1
Switch 11 0 | 1
Switch 12 0 | 1
Switch 13 0 | 1 | 2
Switch 14 0 | 1 | 2
Switch 15 0 | 1 | 2
Switch 16 0 | 1 | 2
Switch 17 0 | 1 | 2
Switch 18 0 | 1 | 2
Switch 19 0 | 1 | 2
Switch 20 0 | 1 | 2
Switch 21 0 | 1 | 2 | 3
Switch 22 0 | 1 | 2 | 3
Switch 23 0 | 1 | 2 | 3
Switch 24 0 | 1 | 2 | 3
Switch 25 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9
Switch 26 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9
Switch 27 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9
Switch 28 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9
