Cumulative CB tripping currents diagnostic LEDs SumI-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Cumulative CB tripping I^2t diagnostic LEDs SumI^2t-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Circuit breaker opening time diagnostic LEDs tbreak-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
CT supervision - 74CT
74CT Enable 74CT Enable OFF | ON
74CT Threshold S< 0.10 ... 0.95 step = 0.01
74CT Overcurrent threshold
State OFF | ON
Pickup value In 0.10 ... 1.00 step = 0.01
S< Operating time
Value s
0.03 ... 9.99 step = 0.01
10.0 ... 99.9 step = 0.1
100 ... 200 step = 1
S< Logical block S<BLK1 OFF | ON
S< Trip relays S<TR-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
S< Trip LEDs S<TR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Remote tripping
Remote tripping relays RemTrip-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Remote tripping LEDs RemTrip-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Pilot wire diagnostic
BLOUT1 Diagnostic pulses period PulseBLOUT1 OFF | 100ms | 1s | 5s | 10s | 60s | 120s
BLIN1 Diagnostic pulses control time interval PulseBLIN1 OFF | 100ms | 1s | 5s | 10s | 60s | 120s
Not received pulses at BLIN signalling relays PulseBLIN-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Not received pulses at BLIN signalling LEDs PulseBLIN-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Demand measures
Fixed demand period tFIX min 1 ... 60 step = 1
Rolling demand period tROL min 1 ... 60 step = 1
Number of cycles for rolling on demand N.ROL 1 ... 24 step = 1
Oscillography
Readings
State
Initialization | Start recording | Acquire | Trigger |
Stopped | Wait | Fail | Off
Records 0 ... 0 step = 0
Buffer storage % 0 ... 0 step = 0
Trigger Setup
Pre-trigger time s 0.05 ... 1.00 step = 0.01
Post-trigger time s 0.05 ... 60.00 step = 0.05
Element pickup trigger ON | OFF
Trigger from outputs K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Binary input trigger ON | OFF
Trigger from inputs IN1-IN32
IN1 | IN2 | IN3 | IN4 | IN5 | IN6 | IN7 | IN8 | IN9
| IN10 | IN11 | IN12 | IN13 | IN14 | IN15 | IN16 |
IN17 | IN18 | IN19 | IN20 | IN21 | IN22 | IN23 |
IN24 | IN25 | IN26 | IN27 | IN28 | IN29 | IN30 |
IN31 | IN32
Trigger from inputs IN33-IN45
IN33 | IN34 | IN35 | IN36 | IN37 | IN38 | IN39 |
IN40 | IN41 | IN42 | IN43 | IN44 | IN45
80% Buffer alarm OFF | ON
Set sample channels
iL1 On | Off
iL2 On | Off
iL3 On | Off
iE On | Off
uE On | Off
Set analog channels
