Tide TEVS10-K07 - Product Overview; Product Design and Specifications; Product Dimension and Size

Product OverviewProduct Overview
5
4
* Appearance may change without notice for quality improvement
Index Description
Model Name TEVS10-K07
Touch Type Touch Button
Display Type OLED
Input Voltage / Frequency Single-Phase AC230V / 50Hz
Output Voltage / Frequency Single-Phase AC230V / 50Hz
Output Power (Max) / Frequency 7kW(32A) / 50Hz
Charing Processor OCPP 1.6
Protection Surge Protection Circuit, Earth Leakage Breaker
IP Level IP55
Constant 1000 Pulse/kWh
Maximum Tolerance ±1%
Charing Connector
AC 7 Pin Type 2
IEC/EN 62196.1-2014, IEC/EN 62196.2-2017
Earth Leakage Breaker AC 230V, 40A / A Type
Dimension 235(W)mm x 364(H)mm x 154(D)mm
Warranty Within one year after purchasing
Product Dimensions and SizeProduct Design and Specifications
Product Overview Product Overview
