MEI CashFlow Manual Cleaning
NOTE: It is recommended that the Bill Acceptor is manually cleaned
every thirty days or every 20,000 bills, whichever occurs first.
Step 1: Remove the Cassette from the Bill Acceptor.
Step 2: Remove the Acceptor “head” by pressing up on the release
bar while pulling outward.
Step 3: Open the clamshell by pulling the clamshell release cover
toward the bill insertion throat while opening the clam-
shell.
Step 4: Press the roller release button to remove the Roller Assem-
bly and clean the rubber rollers (Bulk Note Feeders only).
Step 5: Clean the Sensor lenses and rollers with a damp cloth.
Bill insertion throat
Clamshell release cover
Clean the sensor lenses
and rollers inside the
clamshell
Press in on the yellow release button
to remove the roller assembly
(Bulk Note Feeders)
