Tidel TACC - TACC-III Component Location

TACC-III Component Location
1) Tube Loading Gate Lock
2) Data Key Reader
3) Removable Bezel (for Screen Protector replacement)
4) Drop Chute Handles
5) Printer Paper Loading Door Release Button
6) Integrated Printer
7) Main Vault Door Handle
8) 3 Amp Slow Blow Fuse
9) Rest Button
10) Serial Number Sticker
11) Paper Feed Button
2
1 2
3
4
5
8
9
4
6
7
11
10
