TigerStop TigerFence - M Otor C over a Ssembly; Tigerstop Standard Controller Assembly

4 5
Parts Inventory
PART
DESCRIPTION
NUMBER
QUANTITY
Motor Cover
(S0601-1)
1
M4x8mm
Button-Head Cap Screw
(F9859)
3
PART
DESCRIPTION
NUMBER
QUANTITY
TigerStop
®
Standard
Controller
(CON5)
1
Power Cable
(PC)
1
Data Cable
(CC5-XX)
1
Motor Cover Assembly
TigerStop
®
Standard Controller Assembly
Parts Inventory
PART
DESCRIPTION
NUMBER
QUANTITY
Controller Stand Top
(M1803)
1
Square Tube
(M1808)
1
Round Tube
(M1807)
1
Controller Stand
Base Bracket
(M10070)
2
M6x14mm
Socket-Head Screw
(F7216)
1
M6x10mm
Socket-Head Screw
(F7208)
1
M8x50mm
Hex-Head Screw
(F9827)
1
M8x45mm
Hex-Head Screw
(F9826)
2
Spacer
(F6702)
1
M8x35mm
T-Bolt
(F0184)
2
M8
Flange Nut
(F0419)
5
Controller Stand Assembly
