TigerStop TigerFence - Parts Inventory; Mounting Template Assembly; Mounting Bracket Assembly

2 3
Parts Inventory
PART
DESCRIPTION
NUMBER
QUANTITY
TigerFence Body
(SA8024)
1
Body Handle
(F2232)
1
Ripping Fence
(XA0912-X)
1
Body Assembly
PART
DESCRIPTION
NUMBER
QUANTITY
Clamp Bar
(M0477-1)
1
M10x16mm
Shoulder Bolt
(F1094)
1
Limit-Switch Post
(F2243)
1
Carriage Assembly
Parts Inventory
PART
DESCRIPTION
NUMBER
QUANTITY
Mounting Template
(SA8083)
1
5/16”-18
T-Bolt
(F0177)
8
5/16”
Washer
(F1670)
8
5/16”
Locking Washer
(F1675)
8
5/16”-18
Hex Nut
(F0410)
8
PART
DESCRIPTION
NUMBER
QUANTITY
Mounting Bracket
(TF-MB)
1
M8x30mm
Socket-Head Screw
(F1945)
3
M8x35mm
T-Bolt
(F0184)
3
5/16”
Locking Washer
(F1675)
3
M10
Locking Washer
(F7690)
3
M8
Hex Nut
(F7581)
6
Mounting Template Assembly
Mounting Bracket Assembly
