Before You Start
TW-2HD, TW-5, TW-6 OPERATOR’S MANUAL
NOTE
Table grates are heavy. You will want to get someone
to help you install it on the splitter.
1. Pick up the table grate, holding it by the sides
2. Slide the grate into place with the pipes slipping
under the wings
3. Align the table grate so the mounting tabs slip into
the mount
• Gasoline tank should be full
• Engine oil must be up to fi ll pipe level
• Hydraulic oil must be two (2) to four (4) inches below the top of the tank or in the middle of the sight
level gauge.
• Timberwolf recommends use of ISO 46 for hydraulic oil
Wings
Mounting Tab
Attaching the Table Grate
Check All Fluids
