20
Operating Instructions
Wedge Lift Operation
The wedge lift provides up to four inches of vertical adjustment of the slip-on wedges.
1. Adjust slip-on wedge height while log is on the cradle and before splitting
2. Move handle away from the wedge to raise wedge
3. Move handle toward the wedge to lower wedge
4. Complete the splitting cycle
Note
The wedge lift moves only while handle is held in the desired position.
TW-2HD, TW-5, TW-6 OPERATOR’S MANUAL
WARNING!
Walk around the trailer hitch when moving between the two operator zones.
1. Move the log lift lever towards the wedge to fully lower the lift platform
2. Roll a log (less than 500 lbs) onto the lift platform
3. Move the log lift control valve handle away from the wedge to raise the lift platform until the log rolls onto the cradle
4. Return from the log lift operator zone to the splitting operator zone
5. Keep lift raised while starting the splitting cycle
6. Complete the splitting cycle. (You cannot operate the log lift and split at the same time. Raising or lowering the lift while splitting will
interrupt the cylinder travel)
Using The Log Lift
